Carling F-Series Heavy Duty AC Rated Toggle Switch – 2 Position 10Amp 240V / 15Amp-125V
The F-Series single toggle switches feature a slow-make, slow-break contact mechanism. They are AC rated and are also suitable for low voltage DC rated applications. They fit the industry standard .500 diameter mounting hole. These switches are available in a wide range of momentary and maintained single or double throw circuits, terminations, and bushing/toggle configurations.
| Certifications | UL CSA |
| Number of Poles | 1 |
| Ratings |
10A 250VAC |
| Dielectric Strength | 1,000 V RMS (minimum) |
| Insulation Resistance | 100 megohms (minimum) |
| Base Material | Phenolic |
| Actulator Material | Brass/Nickel Plate |
| Brushing Material | Brass/Nickel Plate |
| Mounting Method | Brushing Mount |
| Mounting Hole Dimensions | .500″ diameter; 12.70mm diameter |
